撒布車液壓油箱的使用與維護保養
來源：http://hk-pinyan.cn/ 日期：2023-07-03
液壓油箱位于前倉內，配裝于前倉倉壁上，主要起到降溫散熱的作用。下面水泥撒布車出租人員為你講解一番：
The hydraulic oil tank is located in the front compartment and is installed on the wall of the front compartment, mainly for cooling and heat dissipation. Below, the rental personnel of the cement spreader truck will explain to you:
1、液壓油觀察孔
1. Hydraulic oil observation hole
液壓油觀察孔上有紅點標注，一般液壓油不要超過紅點即可。
There is a red dot mark on the hydraulic oil observation hole. Generally, hydraulic oil should not exceed the red dot.
2、手、自動切換開關
2. Manual and automatic switching switch
一般情況下處于自動常開位置，自動狀態下散熱風扇會自動開啟，手動狀態下散熱風扇為常開。
Generally, when it is in the automatic normally open position, the Computer fan will automatically start under the automatic state, and the Computer fan is normally open under the manual state.
3、保險
3. Insurance
打開旋轉開關后即可看到內部的保險晶體管
After turning on the rotary switch, you can see the internal fuse transistor
4、散熱風扇
4. Computer fan
當液壓油油溫45℃時散熱器會自動開啟降溫，溫度低于45℃時散熱風扇自動停止。
When the hydraulic oil temperature is 45 ℃, the radiator will automatically start to cool down, and when the temperature is lower than 45 ℃, the Computer fan will automatically stop.
5、溢流管
5. Overflow pipe
主要起到液壓油溢流的作用
Mainly plays a role in hydraulic oil overflow
平時使用的時候我們要注意以下幾點：
When using it regularly, we should pay attention to the following points:
（1）、液壓油的補加
(1) Hydraulic oil replenishment
液壓系統所使用的液壓油為46#高清潔抗壓耐磨液壓油，補加的時候要特別注意，一定要把加油口處的粉塵清理干凈，并適量補加，不要超過觀察孔處的紅色點位，以免液壓油加多了產生外溢。如有外溢，請不要用水清洗，可選擇擦拭清理的方式處理。
The hydraulic oil used in the hydraulic system is 46 # high clean, pressure resistant, and wear-resistant hydraulic oil. Special attention should be paid when adding it. The dust at the oil filling port must be cleaned and an appropriate amount should be added, not exceeding the red dot at the observation hole, to avoid overflow caused by adding too much hydraulic oil. If there is any overflow, please do not use water to clean it. You can choose to wipe and clean it.
（2）、液壓油箱的吹掃
(2) Purging of hydraulic oil tank
因工作環境特殊，粉塵量較大，液壓油箱的散熱片會沾附較多粉塵，粉塵的沾附會影響液壓油油溫的下降并增加散熱風扇的運轉時間。因此，油箱散熱片需要定期吹掃，吹掃的時候氣槍不要離散熱片過近，以免碰傷散熱片。
Due to the special working environment and large amount of dust, the radiator of the hydraulic oil tank will be stained with more dust, which will affect the drop of the hydraulic oil temperature and increase the running time of the Computer fan. Therefore, the fuel tank heat sink needs to be regularly purged, and the air gun should not be too close to the heat sink during purging to avoid damaging it.
（3）、溢流管
(3) Overflow pipe
溢流管可能會因工作環境或其他原因產生溢流，正常使用的時候可能會有部分師傅為了維持前倉的清潔選擇在溢流管下方配裝一個瓶子，此時應特別注意，溢流管的下端不能沒入到瓶?jī)?nèi)的液壓油內，以免瓶?jī)?nèi)不清潔的液壓油因壓力等原因回吸到油箱內，污染液壓系統的清潔度，甚至產生相關的車輛故障。
The overflow pipe may overflow due to working environment or other reasons. During normal use, some workers may choose to install a bottle under the overflow pipe to maintain the cleanliness of the front compartment. At this time, special attention should be paid to the bottom of the overflow pipe not to fall into the hydraulic oil inside the bottle, to prevent the unclean hydraulic oil inside the bottle from being sucked back into the oil tank due to pressure or other reasons, which may contaminate the cleanliness of the hydraulic system, Even related vehicle malfunctions may occur.
（4）、液壓油箱相關連接管件
(4) Hydraulic oil tank related connecting pipe fittings
液壓油箱相關連接管件需要定期檢查，查看有無松動現象，如有松動，及時復緊，以免產生液壓油滲漏。
The relevant connecting fittings of the hydraulic oil tank need to be regularly inspected to see if there is any looseness. If there is looseness, it should be re tightened in a timely manner to avoid hydraulic oil leakage.
應特別注意，液壓油箱散熱風扇雖然會自動開啟降溫，但在使用過程中也會存在一定量的粉塵堆積，粉塵的堆積會影響散熱片的散熱效果，也會影響風扇的開啟與關閉時間，影響著散熱風扇的使用壽命。更多相關事項就來我們網站http://hk-pinyan.cn咨詢吧！
Special attention should be paid to that although the Computer fan of the hydraulic oil tank will automatically turn on for cooling, there will also be a certain amount of dust accumulation in the use process. The accumulation of dust will affect the heat dissipation effect of the cooling fin, the opening and closing time of the fan, and the service life of the Computer fan. For more related matters, come to our website http://hk-pinyan.cn Consult!
